Description
Brand OMRON
Manufacturer Part Number
G3NA-210B-UTU DC5-24SeriesG3NA
Series Relay Mounting
Style
Surface
Electrical Connection Type Screw Switch Configuration
Form AInput Current0.6 to 15 A
Input Voltage5 to 24V DC
Output Voltage24 to 240V AC
Voltage/Current Type AC Output
Output Switching Mode Zero Crossing Current
TypeDCHeat Sink Not Included Maximum Output Current with Heat Sink10 A
Maximum Output Current without Heat Sink4 A
Switch Component Type Phototriac Finger
Safe
Yes
Electrical Phas eSingle Status Indicator LED Indicator Minimum Operating Temperature-22 °F Maximum Operating Temperature176 °FInsulation Resistance100 megaohmBody Depth0.98 inBody Height2.28 inBody Width1.69 inStandardsCE Certified; CSA Certified; TUV Certified; UL ListedUNSPSC39121542
