Description
System Compatibility: Single-stage conventional gas/oil/electric/hydronic; single-stage heat pump (with or without aux); 250–750 mV millivolt heating; 2-wire hydronic zone systems
Display Size: 4.4 sq. in. bright blue backlit LCD
Programming: Non-programmable (manual setpoint)
Power Options: 24 VAC (18–30 VAC) and/or 3.0 VDC from two “AA” alkaline batteries
Electrical Rating: 24 VAC; 1 A max load per terminal; 3 A total max load (all terminals)
Control Range: 45–90°F (7–32°C)
Display Range: 35–99°F (1.5–37°C)
Temperature Accuracy: ±1°F (±0.5°C)
Temperature Differential: Selectable 0.5, 1, or 2°F (0.2, 0.5, or 1°C)
Terminals: Rc, Rh, W1, Y1, G, O, B, C
Dimensions (H × W × D): 4.25″ × 5.12″ × 1.0″
Operating Humidity: 5–95% RH, non-condensing
Replaces
Honeywell: TH1110, TH3110
Emerson: 1F86-0244, 1F83C-11NP
Pro1: T601-2, T701
